Transparent LCD Display- The Future of Digital Signage

TDD-CD-TLD series Transparent LCD screens and Displays are the latest innovation in Transparent LCD technology, opening up a wide range of new opportunities in retail, marketing, showroom window, culture window, glass case, showcase, counters, exhibition stands, furniture, cabinets, POS displays, display cases, shopfitting and integration. We TDD have our own range of Transparent Screens / Displays, Transparent Video Screen, Transparent LCD / LED Display Boxes, Transparent LCD Screen, Transparent LCD Display Box, Transparent LCD Showcase, Capacitive / Infrared Touch Transparent LCD Screen, Capacitive / Infrared Touchscreen Transparent LCD Display Cabinet, and we can not only offer more sizes than anyone else in the world, but also guarantee stable supply, long term availability LCDs with amazing quality. The technology allows you to display information / promotions on the digital display, whilst allowing you to see through it.

Specifications

Features:
Standard diagonal screen sizes: 12’' to 98’’ (customized)
Up to 4K UHD resolution
Media Board with VGA, HDMI and USB to support local media playback
Remote IR sensor
Optional PCAP and IR Multi Touch Screens
Standard sizes for legibility and compatibility with existing content
No special software required
Stunning high resolution images
Industrial grade LCD solutions for optimum performance and reliability
Connect to existing Media Players, PCs and more via HDMI

Functions:
Support audio formats, 1080P full HD loop play, and advertising timing loop playing
Supports timing automatic power-play, automatic shutdown
Supports Android System
Support a variety of android devices remote control, edit content synchronization. Update, expand business opportunities

Configuration:

Size	Resolution  Ratio	Power	Display size (mm)	Stand-Alone	Android system four core CPU1+8G memory			Windows system, I3/4G/SSD128G
				Back door	Back door	Front door	Back door	Back door	Front door	Back door
12	1024*768	24v/50w	261.1*163.2	√	√
19	1366*768	24v/60w	409.8*230.4	√	√			√
22	1680*1050	24v/80w	476.0*267.8	√	√		√	√		√
23.6	1366*768	24v/80w	521*293	√	√			√
32	1920*1080	24v/100w	697.7*392.3	√	√	√	√	√	√	√
43	3840*2160	24v/120w	941.2*529.4	√	√	√	√	√	√	√
49	3840*2160	24v/140w	1073.78 *604	√	√	√		√	√
55	1920*1080	24v/160w	1209.6*680.4	√	√	√		√	√
65	3840*2160	24v/180w	1428.5*803.5	√	√	√		√	√
70	3840*2160	24v/300w	1538.9*865.6	√	√			√
75	3840*2160	24v/300w	1649.7*927.9	√	√			√
80	1920*1080	24v/300w	1771.2*996.3	√	√			√
85	3840*2160	24v/400w	1872*1053	√	√			√
90	1920*1080	24v/400w	1992.9*1121.1	√	√			√
98	3840*2160	24v/600w	2158.9*1214.4	√	√			√
Accept custom requirements					Infrared touch		Capacitive touch	Infrared  touch		Capacitive touch


OS & Software:
Window XP / WIN 7 / Win10 / Android available, all hardware drivers available.

Dimensions:
Height: 595mm (Subject to Change)
Width: 440mm (Subject to Change)
Depth: 485mm (Subject to Change)

Packing:
Bubble-wrap, Carton, Wood (Plywood) Crate

Applications
Custom Displays, Wall Mount / Freestanding / Floor Standing Smart Mirror Displays, Smart Mirrors, Android Smart Mirrors, Stretched Displays, Transparent LCD Displays / Box, LCD Transparent Touch Screen, 3D Holographic Displays / Boxes, Magic Mirrors, Smart Mirror Displays, Smart Bathroom Mirror, ZigBee Smart Home Automation, Touchscreen Android with Magic Mirror, Smart Mirror with 13.3’’, 15.6’’, 21.5’’ and 23.6’’ LED Screen, Mirror Displays, Magic Mirror Displays, Waterproof TV, Mirror TV, Kitchen TV, Outdoor TV, Mirror AD Players, Smart Cabinet Doors, Hotel Bathroom TV, Mirror Built-in TV, Stretched LCD, Bar LCD Monitors, Transparent LCD Displays, Transparent LCD Touch Screen, 3D Holographic Display Box, China Custom Jewelry 3D Displays, 3D Integrated Holographic System for Advertising, Mirror TV Screens, Mirror Glass, Mirror Advertising, Professional Mirror Displays, Transparent LCD / LED Display Boxes, Transparent LCD Screen, Transparent LCD Display Box, Transparent LCD Showcase, Capacitive / Infrared Touch Transparent
LCD Screen, Capacitive / Infrared Touchscreen Transparent LCD Display Cabinet, Advertising Kiosks, China Kiosks Manufacturers
